The main process of waste incinerator system process:
1. The waste is transported by the hydraulic push rod into the waste incinerator, and the material goes to the end of the kiln in the same direction.
2. The waste is incinerated under the action of combustion and combustion, the smoke and dust generated by the rotary kiln enters the secondary combustion chamber, and the slag generated by the incineration is discharged by the wet scraper machine.
3. The smoke and dust waste gas produced by incineration treatment is further incinerated by natural gas in the second combustion chamber, and the combustion temperature is increased to 1100°C-1200°C to make the incineration treatment more thorough, so as to achieve smokeless, odorless, and no secondary environmental pollution Effect.
4. The smoke and dust exhaust gas from the second combustion chamber enters the waste heat and hot water heat exchange system to heat soft water for processing.
5. The smoke and dust exhaust gas enters the semi-dry quenching tower. Water spray cooling is used to control the temperature to quickly drop to about 200°C within 1 second, thereby effectively inhibiting the regeneration of dioxins.
6. The smoke and dust exhaust gas enters the dry acid removal and dioxin adsorption equipment to further purify the exhaust gas. The function of spraying slaked lime is to remove acidic components such as HCl and SOx in the exhaust gas of adsorption dust, and the function of activated carbon is to adsorb and remove a small amount of dioxin furans remaining in the exhaust gas of smoke and dust.
7. The exhaust gas enters the air box type bag filter to remove the fine dust remaining in the exhaust gas. When the inlet temperature of the bag filter is not within the limit value range, the bag bypass solenoid valve is opened, and the smoke and dust exhaust gas enters the chimney through the bypass, effectively ensuring that the bag will not be fatally damaged when the flue temperature is abnormal.
8. The exhausted soot and exhaust gas enters the spray scrubber and wet packing scrubber equipment, the main function is to further remove the acid gas and then discharge it through the chimney.Hazardous waste incinerator, waste gas and waste liquid incineration, medical waste incinerator, domestic waste incineration, municipal waste incineration,  Huatai supply msw incinerator, msw treatment, any need please email to info01@cnoilmachine.com
